MF74 25A NTC Negative Temperature Negative Temperature Coefficient Super Power NTC Thermistor MF74 2.5/25 2.5 OHM 25A

MF74 25A NTC Negative Temperature Negative Temperature Coefficient Super Power NTC Thermistor MF74 2.5/25 2.5 OHM 25A
Features Gallery Product Description Request A Quote
Features
Specifications
Basic Infomation
Place of Origin: China
Brand Name: MF74 25A NTC Negative Temperature
Model Number: MF74 2.5/25
Payment & Shipping Terms
Product Description

II Application Of The Ultra Big Power NTC Thermistor MF73



◎ Power conversion, switch power, UPS power
◎ All kinds of super-power lamps
◎ Electrical heater

MF74 25A NTC Negative Temperature Coefficient Thermistor sensor 2.5Ohm 25mm 1





III Dimension Of The Ultra Big Power NTC Thermistor MF73



MF74 25A NTC Negative Temperature Coefficient Thermistor sensor 2.5Ohm 25mm 2





IV Specification Of The Ultra Big Power NTC Thermistor MF73



P/N R25±20%(Ω) Max steady state current Imax(A) Approx R of Max current Rmax(Ω) Thermal time constant (mW/C) Thermal time constant (s)
MF74-0.5/40 0.5 40 0.00875 118 340
MF74-1/32 1 32 0.0137 118 340
MF74-2/25 2 25 0.024 120 340
MF74-5/21 5 21 0.0364 123 350
MF74-10/18 10 18 0.0555 125 360
MF74-20/15 20 15 0.0745 125 345

MF74 25A NTC Negative Temperature Coefficient Thermistor sensor 2.5Ohm 25mm 3



V Characteristics Of The Ultra Big Power NTC Thermistor MF73



◎ Reliable Configuration and convenient installment
◎ Have the strongest capability of surge current protection
◎ Maximum steady state operating current
◎ Persistnat operating when passing through larger steady state current





VI Ampfort Advantage Of The Ultra Big Power NTC Thermistor MF73



* Product R&D and production Base
* Only direct factory marketing windows
* On behalf of buy ,inspection ,delivery , payment
* Low cost shippment advisor
* Provide technical supoort & advices freely for whole course





VII Key Benefits Of The Ultra Big Power NTC Thermistor MF73





* High Power NTC Thermistor Key Benefits:
* Recognized By Underwriters Laboratories For Ensured Safety
* Designed To Withstand High Steady Sate Current
* Absorbs And Minimizes High Input Energy
* Cost Effective One Component Solution To Inrush Current
* Wide Temperature Range Of Operation





VIII About AMPFORT Of The Ultra Big Power NTC Thermistor MF73



Aolittel Electronics, National Hi-Tech Enterprise and drafting member of “National Thirteen Five Plan”,specilized in manufacturing sensitive elements as NTC/PTC thermistor,NTC temperature sensor and metal oxide varistor. With unique process and advanced technology , product produced with high precision,high reliability,high stability etc outstanding advantages, becoming leading level in the industry. Based on current standard power type MF72 NTC thermistors and “The engineer and research technology center of NTC thermistor ceramic material ” ,applied with new materials/technology/process/equipment,as well as unremitting efforts, innovated MF73T,MT73,MF74,MF75 etc. new power type NTC thermistor and mass production to be realized,key technology has been got big breakthrough and performances has been increased a lot.We have our own proprietary intellectual property right and dozens of patents, it can provide inrush protection in industrial level application and it is originate in domestic !

MF74 25A NTC Negative Temperature Coefficient Thermistor sensor 2.5Ohm 25mm 5

A glance at workshop and R&D center
16 years’ experience R&D center and modern factories cover an areas of 120 mu .





VIIII Package Details Of The Ultra Big Power NTC Thermistor MF73



little box: 18*11.5*8cm

Whole box : 28*19*7cm

Clamshell box: 28.3*19*7.3cm 0.002CBM

Heightening box:28*19.5*11.5cm 0.004CBM

Clamshell box:28.3*19*7.3 0.004CBM

Small box: 30*22*24.5cm 0.004CBM

Big box: 40.5*31*24.5cm 0.031CBM

Braid box: Braid boxcm 0.052CBM
